Features

Applications

Low Insertion Loss

EDFA

High Return Loss

Pump Laser

High Reliability & Stability

Q-Switched Laser

Specifications

Parameters

Unit

Values

Pass Band Wavelength Range

nm

900~990, or Specified

Max.Insertion Loss over Pass Band Wavelength

dB

0.7

Blocked Band Wavelength Range

nm

1020~1100, or 1500~1600, or Specified

Min. Isolation

dB

25

Max. Polarization Dependent Loss

dB

0.15

Min. Return Loss

dB

30

Max. Power Handling (CW)

W

30

Max. Wavelength Thermal Stability

nm/℃

0.003

Max. Insertion Loss Thermal Stability

dB/℃

0.005

Fiber Type

-

Multi-mode fiber: 105/125,62.5/125, 50/125um

Operating Temperature

℃

0~+70

Storage Temperature

℃

-40~+85

For device with connector, IL is 0.3dB higher, RL is 5dB lower, ER is 2dB lower.

For device with connector, handling power is only 1W.

The default connector key is aligned to slow axis.

    MMPLP-1111-222-345-66-7788

1111

-Operating Wavelength:

9815=980nm pass/1550nm blocked, 9806=980nm pass/1064nm blocked

222

-Fiber Type:

009=Nufern Nufern MM-S105/125-22A

3

-Package Dimension：

1=0=φ5.5x35mm, S=Specified

4

-Pigtail Type:

0=250μm bare fiber, 1=900μm loose tube

5

-Fiber Length:

0=0.8m,1=1m

66

-Connector Type:

0=FC/UPC,1=FC/APC,2=SC/UPC,3=SC/APC,4=LC/UPC,5=LC/APC

77

-Average Power:

00=500mW, 01=1W,......, 30=30W

88

-Peak Power:

10=10kW, 20=20kW
