Features

Applications

Low Insertion Loss

Testing Instrument

High Return Loss

Raman Fiber Laser

High Isolation

Ultra-fast Fiber Laser

High stability & Reliability

Specifications

Parameters

Unit

Value

Center Wavelength

nm

633

Operating Wavelength Range

nm

±10

Min. Isolation at 23℃

dB

20

Typ. Insertion Loss at 23℃

dB

1.8

Max. Insertion Loss at 23℃

dB

2.2

Min. Return Loss at 23℃ (Input /Output)

dB

30

Max. Optical Power (CW)

mW

300

Max. Tensile Load

N

5

Fiber Type

-

MM50/125 or MM62.5/125

Package Dimension

mm

44x28x26

Operating Temperature

℃

+10~+50

Storage Temperature

℃

0~+60

*With connectors, the Max. handing power is 100mW only, IL is 1.0dB higher and RL is 5dB lower.

Ordering Information

MMIS-①①①-②-③③③-④⑤-⑥-⑦⑦-⑧⑧⑨⑨

①①①

- Center Wavelength:

 633=633nm, SSS=Specified

②

- Working Axis:

 N=Non-PM

③③③

- Fiber Type:

 093=MM62.5/125, 094=MM50/125, SSS=Specified

④

- Pigtail Type:

 0=250μm bare fiber, 1=900μm loose tube

⑤

- Package Dimensions:

 0=44x28x26mm

⑥

- Fiber Length:

 0.8=0.8m, 1.0=1m, S=Specified

⑦⑦

- Connector Type:

 0=FC/UPC, 1=FC/APC, 2=SC/UPC, 3=SC/APC, 4=LC/UPC, 5=LC/APC, N=None

⑧⑧

- Average Power:

 00=300mW

⑨⑨

- Peak Power:

 00=Continuous Wave, 01=1kW, 02=2kW, SS=Specified
