Features

Applications

Low Insertion Loss

Fiber Optic Instruments

High Return Loss

Fiber Sensors

High Reliability

Fiber Lasers

High Stability

Coherent Detecting

Research

Specifications

Parameters

Unit

Value

Center Wavelength

nm

1310 or 1550

1064

Operating Wavelength Width

nm

±15

±5

Max. Insertion Loss

dB

0.6

0.8

Min. Extinction Ratio at 23 ℃, only for PI

dB

20

Max. Polarization Mode Dispersion

ps

0.05

Max. Power Handling

mW

500

Max.Tensile Load

N

5

Operating Temperature

℃

-5~+70

Storage Temperature

℃

-40~+85

     PMFM-1111-222-345-6

1111

-Center Wavelength:

1550=1550nm,1310=1310nm,......,0850=850nm

2

-Fiber Type:

001=PM1550, 002=PM1310, 003=PM980, 004=Hi1060, 008=SMF-28E

3

-Package Dimension：

0=φ5.5x35mm, S=Specified

4

-Pigtail Type:

0=250μm bare fiber, 1=900μm loose tube

5

-Fiber Length:

0=0.8m,1=1m

6

-Connector Type:

0=FC/UPC,1=FC/APC,2=SC/UPC,3=SC/APC,4=LC/UPC,5=LC/APC, N=None
